• Country
• Germany

• Manufacturer / Brand
• Rosita, Theo Schmitz GmbH (Audion); Paderborn

• Year
• 1977/1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 124730

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Details
• Other Combination - see Notes

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: KL3800 - Rosita, Theo Schmitz GmbH

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 970 x 280 x 360 mm / 38.2 x 11 x 14.2 inch

• Notes

• Kompaktanlage mit Stereo-Steuergerät Loewe R3800;
  Phono-Chassis = Elac 831;
  Cassetten-Recorder = Grundig CN830.
  Gehäuse nussbaumfarbig hell, anthrazit oder Schleiflack weiss.
  Vier Lautsprecherausgänge (Quadro).

• Net weight (2.2 lb = 1 kg)
• 25.5 kg / 56 lb 2.7 oz (56.167 lb)

• Source of data
• Handbuch VDRG 1977/1978

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
