Jubilee 12 Transistor RE-121
Ross Electronics Corp.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Ross Electronics Corp.; Chicago (IL)
- Year
- 1967 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 341401
Made in Hong Kong
- Number of Transistors
- 12
- Semiconductors
- 2SA29 2SA15 2SA12 2SA12 unknown_tr_PNP unknown_tr_PNP unknown_tr_PNP unknown_tr_PNP 2SB60A unknown_tr_PNP 2SB60A unknown_tr_PNP
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.25 inch = 5.7 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Jubilee 12 Transistor RE-121 - Ross Electronics Corp.;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 2.7 x 4.3 x 1.2 inch / 69 x 109 x 30 mm
- Notes
-
The Ross Jubilee 12 Transistor AM Radio Model RE-121 has the following features:
- Tuning Range: AM 535 - 1605 kHz.
- No CONELRAD Civil Defense (CD) frequency marks.
- Earphone jack.
- Transistors TR5, TR6, TR8 configured as a diodes (TR5/6: Base shorted to Emitter; TR8: Base shorted to Collector).
- Transistors TR9/10 and TR11/12 configured as push-pull Darlington drivers.
Made in Hong Kong
- Net weight (2.2 lb = 1 kg)
- 0.5 lb (0 lb 8 oz) / 0.227 kg
- Literature/Schematics (1)
- Photofact TSM Transistor Radio Series SAMS (TSM-80, March 1967)
- Author
- Model page created by Jerry Elarton. See "Data change" for further contributors.
