Triumph RE-800

Ross Electronics Corp.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1962
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 288757

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast plus 2 Short Wave bands.
  • Power type and voltage
  • Dry Batteries / C: 6 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Triumph RE-800 - Ross Electronics Corp.;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 10 x 7.5 x 2.75 inch / 254 x 191 x 70 mm
  • Notes

  • The Ross Triumph RE-800 is a portable, 3 band AM/SW radio covering .55 to 16 MHz (550-1600 KHz, 1.6-4 MHz, and 6-16MHz). it has a telescopic antenna and a 4 inch Alinco speaker.

  • Price in first year of sale
  • 39.95 USD
  • Mentioned in
  • Radio-TV Experimenter Fall 1962 page 7
  • Author
  • Model page created by Wayne Childress. See "Data change" for further contributors.
