• Country
• Hungary

• Manufacturer / Brand
• Rotand Rádió; Budapest

• Year
• 1933

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 124655

• Number of Tubes
• 3

• Valves / Tubes
• TAF7 unknown_Tube TAZ1

• Conflicting model year with tube data.
• The model date contradicts tube dates. [ TAF7 (1935) TAZ1 (1935)]

• Main principle
• TRF with regeneration

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: Pannónia - Rotand Rádió; Budapest

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 400 x 260 x 190 mm / 15.7 x 10.2 x 7.5 inch

• Price in first year of sale
• 96.00 pengö

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 45 models, 36 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
