AM/FM Stereo Receiver RX-845

Rotel, The, Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1989 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 307585

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 120 or 220 or 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 60 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AM/FM Stereo Receiver RX-845 - Rotel, The, Co., Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 94 x 332 mm / 16.9 x 3.7 x 13.1 inch
  • Notes

  • A Stereo Hi-Fi Receiver with a MW/VHF Quartz PLL Synthesizer Tuner and a 2 x 30 watt Amplifier. Rotary controls for Bass, Mid, Treble, Balance and Volume. Press Buttons for Power, Speaker Selection (A and B), Loudness, Tape Monitor, Function Selection (Video, CD, AM, FM, Phono), FM Mute Off/Mono, FM Auto Tuning, Tuning Up, Tuning Down, Memory Program and Preset Stations (8). Signal Strength Indicators and Stereo Indicator. Frequency Display. Jack for Headphones.

    Continuous Power Output :
    30 watts per channel, min. RMS both channels driven at 8 ohms
    from 20Hz to 20kHz with no more than 0.05% Total Harmonic Distortion

    Speaker load impedance        : 8 - 16Ω (A + B), 4 - 16 (A or B)
    Headphones load impedance : 4 - 16Ω

    Versions/Power Requirements
    120 V AC 60Hz
    220 V AC 50Hz
    240 V AC 50Hz
    120/220/240 V AC 50/60Hz

  • Net weight (2.2 lb = 1 kg)
  • 7.3 kg / 16 lb 1.3 oz (16.079 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Owner's Manual RX-845 AM/FM Stereo Receiver)
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Technical Manual RX-845 AM/FM Stereo Receiver)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
