Integrated Stereo Amplifier RA-713

Rotel, The, Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1976 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 150348

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 120 or 220 or 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 90 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Integrated Stereo Amplifier RA-713 - Rotel, The, Co., Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 143 x 304 mm / 16.9 x 5.6 x 12 inch
  • Notes

  • A 2 x 45 watt integrated hi-fi amplifier. Rotary controls for Bass, Treble, Volume/Balance. Rotary switches for Mode (Rev, Stereo, Mono), Tape Monitor (1 > 2, Tape1, Source, Tape2,  2 > 1) and Function (Tuner, Phono, Aux). Press buttons for Power, Speakers A, B,  Low Filter, High Filter, Loudness and Muting (-15dB). Left and Right Power Meters. Jack for Headphones. Connections for two pairs of loudspeakers.

    Continuous Power Output :
    45 watts per channel, min. RMS both channels driven into 8 ohms or
    55 watts per channel, min. RMS both channels driven into 4 ohms
    from 20Hz to 20kHz with no more than 0.1% Total Harmonic Distortion
    Frequency Response : Phono ............. 30Hz - 15kHz
                                      Aux, Tape In .... 10Hz - 60kHz ± 0.5dB
    Speaker Impedance  :  A,B (4 to 16Ω), A+B (8 to 16Ω)

    Versions/Power Requirements
    120 V AC 60Hz
    220 V AC 50Hz
    240 V AC 50Hz
    100/120/220/240 V AC 50-60Hz Switchable

    Stereo-Vollverstärker mit 2 x 70 Watt Sinus an 4 Ohm.

  • Net weight (2.2 lb = 1 kg)
  • 10.2 kg / 22 lb 7.5 oz (22.467 lb)
  • Source of data
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Technical Manual for the RA-713)
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Owner's Manual for the RA-713)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
