Stereo Integrated Amplifier RA-820AX

Rotel, The, Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1986 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 264287

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 120; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 100 W (110 W max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Integrated Amplifier RA-820AX - Rotel, The, Co., Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 444 x 66 x 303 mm / 17.5 x 2.6 x 11.9 inch
  • Notes

  • Rotel Stereo Integrated Amplifier Model RA-820AX.

    50 Watts RMS per channel into 4 ohm, 1 kHz, < 1% THD.
    30 Watts RMS per channel into 8 ohm, 20 - 20000Hz, < 0,08% THD.
    55 Watts music power per channel into 4 Ohm, < 0,08 % THD.
    Bass- & Treble Control.
    Phono IN, CD IN, Tuner IN, Tape Monitor, AV/AUX.
    Power Consumption 170 Watts @ max output power.

    In some countries the choice between mains voltages is not available: see technical documents.


  • Net weight (2.2 lb = 1 kg)
  • 6 kg / 13 lb 3.5 oz (13.216 lb)
  • Mentioned in
  • - - Manufacturers Literature (Owners Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
