Art Deco (large, 5 tubes) 62/72
Rubis; Fontaine-l'Evêque
- Country
- Belgium
- Manufacturer / Brand
- Rubis; Fontaine-l'Evêque
- Year
- 1936/1937
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 210759
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 110 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110/220 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 19 cm = 7.5 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Art Deco 62/72 - Rubis; Fontaine-l'Evêque
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 800 x 325 x 280 mm / 31.5 x 12.8 x 11 inch
- Notes
-
An Art Deco table was available as accessory.
A smaller version of this radio was also available. This is model 60 (1936) or model 70 (1937). The larger model with 6 tubes is model 63/73.
- Net weight (2.2 lb = 1 kg)
- 19.3 kg / 42 lb 8.2 oz (42.511 lb)
- Mentioned in
- Radios von gestern, 2. Auflage
- Author
- Model page created by Don Palmer. See "Data change" for further contributors.
