• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1960/1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 77733

• • Brand: Schwer & Söhne, GmbH

• Number of Tubes
• 10

• Valves / Tubes
• EC92 EC92 ECH81 EF85 EM84 EABC80 ECL86 ECL86 EABC80 ECL80

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 8 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-200 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 300 Automatic Stereo 125 C - SABA; Villingen

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 1480 x 835 x 430 mm / 58.3 x 32.9 x 16.9 inch

• Notes
• 2 Diodes. Station seeker, Audio-Stereo only. See also the domestic (German) version called: Breisgau-Automatic 125 Stereo..
  Abgleich (auch Steuerfilter)
  Alignment (also automatic filter)

• External source of data
• Karl Schmitz, USA

• Mentioned in
• -- Collector info (Sammler)

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.
