• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1980 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 193840

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: CT310 - SABA; Villingen

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 300 x 65 x 280 mm / 11.8 x 2.6 x 11 inch

• Notes
• Enthält 5IC's, 5 UKW Festsendertasten, Ferritantenne klappbar an Rückwand. Gerät passend zu Saba CI310 Verstärker

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Henning Oelkers. See "Data change" for further contributors.

• Other Models

• Here you find 1645 models, 1501 with images and 1185 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
