Fürstenberg S163 Automatic
SABA; Villingen
- Country
- Germany
- Manufacturer / Brand
- SABA; Villingen
- Year
- 1965/1966
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 327436
-
- Brand: Schwer & Söhne, GmbH
Picture from service manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Number of Transistors
- 4
- Main principle
- Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Fürstenberg S163 Automatic - SABA; Villingen
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 865 x 850 x 440 mm / 34.1 x 33.5 x 17.3 inch
- Notes
-
Saba, Fürstenberg S163 Automatic
- 59 cm Fernsehgerät
- UHF Transistor Tuner.
- Empfangsbereiche
- VHF-Bereich: Kanäle 2 - 12
- UHF-Bereich: Kanäle 21 - 68
- Lautsprecher 2 Stück 19 x 10,5 cm.
- Antenneneingang 240 Ohm symmetrisch.
- Net weight (2.2 lb = 1 kg)
- 40 kg / 88 lb 1.7 oz (88.106 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
