• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1981/1982

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 137922

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Hifi Cassettendeck CD274 - SABA; Villingen

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 442 x 114 x 340 mm / 17.4 x 4.5 x 13.4 inch

• Notes
• Frontloading 2-Head Stereo Cassette Deck with Dolby B and Metal Tape Capability.
  3-Digit Mechanical Counter, Digital Peak-Reading Meters.

• Mentioned in
• -- Original prospect or advert (SABA Prospekt - "HIFI-Neuheiten 1981/82")

• Literature/Schematics (1)
• Saba Katalog von 1981

• Author
• Model page created by Wolfgang Pohl. See "Data change" for further contributors.
