HiFi-Lautsprecherbox 60G
SABA; Villingen
- Country
- Germany
- Manufacturer / Brand
- SABA; Villingen
- Year
- 1972/1973
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 275138
-
- Brand: Schwer & Söhne, GmbH
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- 4 Loudspeakers
- Power out
- 45 W (60 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: HiFi-Lautsprecherbox 60G - SABA; Villingen
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 320 x 575 x 260 mm / 12.6 x 22.6 x 10.2 inch
- Notes
-
Volumen: 32 L
Bauart: 4 Wege geschlossen
- 1 Tieftöner : 200mm
- 1Tiefmitteltöner : 200mm
- 1 Mitteltöner : 145mm
- 1 Hochtöner: 95mm
Impedanz: 4Ω
- Net weight (2.2 lb = 1 kg)
- 14.5 kg / 31 lb 15 oz (31.938 lb)
- Author
- Model page created by Peter Böhm. See "Data change" for further contributors.
