• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1988

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 166561

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220; 8 x 1,5 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 20 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Stereo Radio Cassette Portable RCP 652 - SABA; Villingen

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 605 x 235 x 170 mm / 23.8 x 9.3 x 6.7 inch

• Notes
• Rundfunkteil mit UKW/ Stereo,MW,LW,KW.
  Automatische UKW- Scharfabstimmung, eingebaute Teleskop und Ferritantenne.
  3- Band Graphic- Equalizer, abnehmbare 2- Wege- Paßreflexboxen.
  Soft- Eject- Cassettensystem mit Autoreverse.
  Ausführung: schwarz

• Net weight (2.2 lb = 1 kg)
• 6.6 kg / 14 lb 8.6 oz (14.537 lb)

• Author
• Model page created by Eduard Abfalterer. See "Data change" for further contributors.
