RCR744 Stereo
SABA; Villingen
- Country
- Germany
- Manufacturer / Brand
- SABA; Villingen
- Year
- 1979
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 142735
-
- Brand: Schwer & Söhne, GmbH
Original prospekt in 1979.
- Number of Transistors
- 15
- Semiconductors
- 2SK49 2SC668 2SC930 2SC1312 2SC693 or. 2SC536 2SB22 2SD545 2SD400 LA3301 M5130P LA4102
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line plus power jack, mostly with battery or storage battery / 220 / 6 x 1.5 / DC 9 Volt
- Loudspeaker
- 4 Loudspeakers
- Power out
- 8 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: RCR744 Stereo - SABA; Villingen
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 420 x 265 x 115 mm / 16.5 x 10.4 x 4.5 inch
- Notes
-
4-Band-Stereo-Radio-Recorder mit 2 x 4 Watt Spitzenleistung. Klangregler für Höhen und Tiefen. Anschluss für 9 V Netzgerät.
Ausführung in Mattschwarz/Metallic.
Timerfunktion des Radios wird über Restlaufzeit einer Kassette gesteuert (maximal 45 min).Zwei Lautsprecher mit je 10 cm Durchmesser, zwei Hochtöner jeweils 2 cm Durchmesser.
Jeder Transistor- bzw. IC-Typ ist einmal gelistet.
Siehe auch das technisch identische Modell Saba RCR 394.
- Net weight (2.2 lb = 1 kg)
- 3.7 kg / 8 lb 2.4 oz (8.15 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
