• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1962–1964

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 24354

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECC85 ECH81 EBF89 ECL86

• Number of Transistors

• Semiconductors
• B250C75 RL232 RL232

• Main principle
• Superheterodyne (common); ZF/IF 460/6750 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 120/220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 3 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Sabine 12 - SABA; Villingen

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 325 x 210 x 180 mm / 12.8 x 8.3 x 7.1 inch

• Notes

• Ratio-Detektor mit Germanium-Dioden.

• Net weight (2.2 lb = 1 kg)
• 5.4 kg / 11 lb 14.3 oz (11.894 lb)

• Price in first year of sale
• 249.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1962/1963

• Mentioned in
• Handbuch RFP 1963
