Sabine UA265
SABA; Villingen
- Country
- Germany
- Manufacturer / Brand
- SABA; Villingen
- Year
- 1956 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 109244
-
- Brand: Schwer & Söhne, GmbH
deremate.cl
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; Export model
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- AC/DC-set / 117/220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 4 W (unknown quality)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Sabine UA265 - SABA; Villingen
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 300 x 200 x 175 mm / 11.8 x 7.9 x 6.9 inch
- Notes
-
Farbe elfenbein oder braun.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Klaus Najman. See "Data change" for further contributors.
