• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1962/1963

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 85936

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• PC88 PC86 PCC88 PCF80 PCF82 EF183 EF80 EF80 EF80 PCL84 EBF89 ECH84 ECH84 PCL85 PL500 PY88 DY86 PCL86 AW59-90

• Number of Transistors

• Semiconductors
• BA101 BY242 OA81 OA160 OA161 RL232

• Main principle
• Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 20 cm = 7.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Schauinsland T128V Vollautomatic - SABA; Villingen

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 685 x 490 x 430 mm / 27 x 19.3 x 16.9 inch

• Notes

• Saba Schauinsland T128V Vollautomatic

  • 59 cm Fernsehgerät mit Telelupe
  • Empfangsbereiche
    • VHF-Bereich: Kanäle 2 - 12 und Reservekanal 1
    • UHF-Bereich: Kanäle 21 - 68
  • Lautsprecher 1Stück 20 cm. Ø und 1 Stück 15 x 8 cm.
  • Antenneneingang 240 Ω symmetrisch.

  Kabel-Fernsteuerung FS 12 für Helligkeit, Telelupe, VHF/UHF und Lautstärke.

• Net weight (2.2 lb = 1 kg)
• 33.5 kg / 73 lb 12.6 oz (73.789 lb)

• Price in first year of sale
• 1,349.00 DM

• Source of data
• Handbuch VDRG 1963/1964

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
