• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1954/1955

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 19699

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 ECH81 EF89 EBF80 EM80 EABC80 EL84

• Main principle
• Superheterodyne (common); ZF/IF 472/10700 kHz

• Tuned circuits
• 8 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player + Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220 Volt

• Loudspeaker
• 3 Loudspeakers

• Power out
• 5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Truhe Schwarzwald W5/1-T - SABA; Villingen

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 730 x 860 x 414 mm / 28.7 x 33.9 x 16.3 inch

• Notes
• Rundfunk-Chassis = Schwarzwald W5;
  Phono-Chassis = Perpetuum Ebner 3425PE;
  Tonband-Chassis = AEG KL25.

• Net weight (2.2 lb = 1 kg)
• 48 kg / 105 lb 11.6 oz (105.727 lb)

• Price in first year of sale
• 1,798.00 DM

• External source of data
• Erb

• Source of data
• Rundfunk- und Fernseh-Katalog 1954/55
