• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1980 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 356053

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Other Combination - see Notes

• Power type and voltage
• Alternating Current supply (AC) / 220-250 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 60 W (96 W max.)

• from Radiomuseum.org
• Model: Ultra HiFi-Center 7900 electronic - SABA; Villingen

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 740 x 190 x 435 mm / 29.1 x 7.5 x 17.1 inch

• Notes

• Kompaktanlage mit Radio, Dual-Plattenspieler 1237A und Kassettendeck.

• Net weight (2.2 lb = 1 kg)
• 17.5 kg / 38 lb 8.7 oz (38.546 lb)

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by a member from D. See "Data change" for further contributors.
