Olympia-Super AK1 (W)
Sachsenwerk (bis 1945) ESWE
- Country
- Germany
- Manufacturer / Brand
- Sachsenwerk (bis 1945) ESWE
- Year
- 1934/1935
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 6464
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz; Super, reaction, but not adjustable
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110, 125, 150, 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Olympia-Super AK1 - Sachsenwerk bis 1945 ESWE
- Shape
- Tablemodel, with any shape - general.
- Source of data
- Radiokatalog Band 1, Ernst Erb
- Circuit diagram reference
- Lange + Schenk
- Other Models
-
Here you find 168 models, 144 with images and 107 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sachsenwerk (bis 1945) ESWE
Collections
The model Olympia-Super is part of the collections of the following members.
