• Country
• Finland

• Manufacturer / Brand
• Salora; Salo

• Year
• 1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 87245

• Number of Tubes
• 5

• Valves / Tubes
• ECH42 EAF42 EF41 EL41 AZ41

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110, 127, 220, 250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: 500V - Salora; Salo

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 460 x 285 x 212 mm / 18.1 x 11.2 x 8.3 inch

• Price in first year of sale
• 19,800.00 FIM

• Mentioned in
• -- Original prospect or advert

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Lasse Nirhamo. See "Data change" for further contributors.

• Other Models

• Here you find 180 models, 149 with images and 59 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
