Stereo Integrated Amplifier K560A

Samsung Co.; Daegu

Data
Forum
Pictures
Collections

  • Year
  • 2000 ??
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 303378

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 50 Hz; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 90 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Integrated Amplifier K560A - Samsung Co.; Daegu
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 420 x 100 x 240 mm / 16.5 x 3.9 x 9.4 inch
  • Notes

  • Mic Mixing Surround System - volume control / treble / bass / balance / mic mixing - remote control system - surround buttons on / off - Tuner / Phono / CD-Aux / TV-Vtr / Tape Monitor - Mute - front headphone jack - LED diodes Vu meter for output / power / volume level - output power: 45 + 45 watt max - impedance 8 Ω speakers - AC outlet switched 50 w max - connectors for tuner / turntable / deck - power consumption 220 watts.

    Mic Mixing Surround System - controllo volume/toni alti/toni bassi/bilanciamento/ mic mixing - remote control system - tasti surround on/off - Tuner/Phono/Cd-Aux/Tv-Vtr/ Tape Monitor - Mute - presa frontale per cuffia - Vu meter a diodi led per uscita/potenza/livello volume - potenza d'uscita: 45 + 45 watt max - impedenza altoparlanti 8 Ω - Ac outlet switched 50 w max -  connettori per tuner/turntable/deck - power consumption 220 watt.

    Made in Republic of Korea.

  • Net weight (2.2 lb = 1 kg)
  • 7.8 kg / 17 lb 2.9 oz (17.181 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
