Stereo Radio Double Cassette Recorder PD-770L
Samsung Co.; Daegu
- Country
- South Korea
- Manufacturer / Brand
- Samsung Co.; Daegu
- Year
- 1991 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 342474
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- PLL, Phase-locked loop
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 50Hz, 220 / D: 6 × 1.5 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Stereo Radio Double Cassette Recorder PD-770L - Samsung Co.; Daegu
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 580 x 205 x 155 mm / 22.8 x 8.1 x 6.1 inch
- Notes
-
Bass Enhancement Super bass, Digital Tuning, Memory Up/Down Tuning, Search, Synthesized Digital Tuning, with 20 preset stations 10 FM and 10 AM, 3-band Graphic EQ, Dual Cassette Deck, High Speed Copy, Automatic recording level control, Timer and clock, Automatic tape end stop, One key recording system, Built-in microphone, 2 x 2-way speakers, Detachable speakers, Output power 18W PMPO.
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
