FM/AM/WX Digital Receiver DT-800

Sangean; Chung Ho City

Dati
Forum
Immagini
Collezioni

  • Anno
  • 2018 ?
  • Categoria
  • Radio (o sintonizzatore del dopoguerra WW2)
  • Radiomuseum.org ID
  • 333123

Clicca sulla miniatura dello schema per richiederlo come documento gratuito.

 Specifiche tecniche

  • Principio generale
  • DSP, Processore di segnale digitale
  • Gamme d'onda
  • Gamme d'onda nelle note.
  • Tensioni di funzionamento
  • Batterie / presa di alimentazione supplementare / AA: 2 x 1.5 or AA: 2 x 1.2 Volt
  • Altoparlante
  • AP magnetodinamico (magnete permanente e bobina mobile) / Ø 2.8 cm = 1.1 inch
  • Potenza d'uscita
  • 0.1 W (indistorta)
  • Materiali
  • Plastica (non bachelite o catalina)
  • Radiomuseum.org
  • Modello: FM/AM/WX Digital Receiver DT-800 - Sangean; Chung Ho City
  • Forma
  • Tascabile (portatile molto piccola), < 20 cm
  • Dimensioni (LxAxP)
  • 68.2 x 115.4 x 26.5 mm / 2.7 x 4.5 x 1 inch
  • Annotazioni

  • The U.S. model variant of the Sangean DT-800 shares a common design with the European model (the Pocket 800) and with the domestic Chinese model (the DT-800C).

    Despite the three model variants sharing a common set of features, each one have unique features suited to the target market.

    Main specifications for the U.S. model:

    • Cabinet colors: Dark-Gray and Yellow
    • Receiver bands:
      • FM-RDS: Selectable between
        • 87-108 MHz
        • 76-108 MHz
        • 64-108 MHz
        • 76-90 MHz
        • Tuning steps: 200 kHz, 100 kHz, 50 kHz, selectable
        • Radio station name with RDS service
      • AM: Selectable between
        • 522-1710 kHz (9k tuning steps)
        • 520-1710 kHz (10k tuning steps)
      • NOAA: 7 Weather Channels
    • Public Alert Certified Weather Radio
    • 45 Memory Preset Stations (20 FM, 20 AM, 5 WX)
    • Manual and Auto scan with ATS
    • Wide/Narrow Bandwith on AM and FM
    • DSP Soft-Mute ON or OFF, selectable
    • Clock with Alarm (Buzzer) and Sleep timer
      • Auto clock sync with RDS CT service
    • Dynamic Bass Boost
    • Battery level indicator
    • Lock switch
    • Stereo Earphone socket (FM)
    • Built-in Speaker
    • Built-in Ni-MH battery charger (USB charger port)
    • Can run on penlight AA batteries, or on Ni-MH rechargealble batteries, selectable at the back of the unit inside the battery compartment.
    • Some production batches offer an AC Adapter able to deliver 5V 500mA



    Please see additional model variants and technical details here: DT-800C

  • Peso netto
  • 0.132 kg / 0 lb 4.7 oz (0.291 lb)
  • Autore
  • Modello inviato da Jose Mesquita. Utilizzare "Proponi modifica" per inviare ulteriori dati.
