Stereo tuner amplifier 5000A

• Country
• Japan

• Manufacturer / Brand
• Sansui Electric Co., Ltd.; Tokyo

• Year
• 1969

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 156341

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 58

• Semiconductors

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 110 W (180 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo tuner amplifier 5000A - Sansui Electric Co., Ltd.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 441 x 139 x 383 mm / 17.4 x 5.5 x 15.1 inch

• Notes
• AM/FM Stereo Receiver, 2 x 55 Watt Sinus an 8 Ohm.
  Ratio-Mitte, Feldstärkeanzeige.
  Anschlüsse für 4 TB und 3 LS-Gruppen.
  4 IC's, 38 Dioden, 2 Zenerdioden.

• Net weight (2.2 lb = 1 kg)
• 16.2 kg / 35 lb 10.9 oz (35.683 lb)

• Price in first year of sale
• 2,200.00 DM

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
