Pure Power DC Stereo Receiver G-5700
Sansui Electric Co., Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sansui Electric Co., Ltd.; Tokyo
- Year
- 1979/1980 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 127555
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 100; 120; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 150 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Pure Power DC Stereo Receiver G-5700 - Sansui Electric Co., Ltd.;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 465 x 177 x 405 mm / 18.3 x 7 x 15.9 inch
- Notes
-
A hi-fi stereo receiver housed in a wooden case with an AM/FM stereo tuner with both analogue dial and digital frequency display and an amplifier with power output of 2 x 75 watts RMS into 8 ohms from 20 - 20,000Hz, THD ≤ 0.03%. Digitally quartz-locked tuning, Peak Power Level indicators. Inputs: phono, aux and 2x tape. Terminals for 2 pairs of loudspeakers.
Stereo-Receiver. Analoge und digitale Frequenzanzeige. LED-Aussteueranzeige. Eingänge: Phono, Aux und 2x Band. Vier Lautsprecherausgänge.
- Net weight (2.2 lb = 1 kg)
- 13.8 kg / 30 lb 6.3 oz (30.396 lb)
- Source of data
- - - Data from my own collection
- Mentioned in
- -- Original prospect or advert (1980 Sansui Hi-Fi Guide)
- Literature/Schematics (1)
- - - Manufacturers Literature (Service manual Sansui G-5700 G-6700 G-7700)
- Author
- Model page created by Peter Böhm. See "Data change" for further contributors.
