• Country
• Japan

• Manufacturer / Brand
• Sansui Electric Co., Ltd.; Tokyo

• Year
• 1975/1976

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 130034

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 100; 110; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo Cassette Deck SC-2002 - Sansui Electric Co., Ltd.;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 440 x 158 x 290 mm / 17.3 x 6.2 x 11.4 inch

• Notes
• Sansui Stereo Cassette Deck SC 2000, black front, standard tape: 30 - 13.000 Hz, CrO² tape: 30 - 15.000 Hz, Dolby NR; DIN, Chinch, Phono & 2 MIC-in terminals, 2 VU meters.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by a member from A. See "Data change" for further contributors.
