Stereo Graphic Equalizer SE-8

Sansui Electric Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1980
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 359813

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz, 100; 120; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Graphic Equalizer SE-8 - Sansui Electric Co., Ltd.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 130 x 277 mm / 16.9 x 5.1 x 10.9 inch
  • Notes

  • Type: Stereo graphic equalizer

    Variable range: ±12 dB, left / right independent Center frequency: 32 Hz, 63 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 4 kHz, 8 kHz, 16 kHz

    Input Sensitivity / Impedance Input: 1 V / 30 kΩ Tape 1, 2: 1 V / 30 kΩ
    Output Level / Impedance: 1 V / 30 kΩ (Rated Output)

    Total harmonic distortion factor: 0.008% (Rated Output)
    Frequency characteristic: 10 Hz ~ 100 kHz +0 -1 dB (Flat Position)
    Signal-to-noise ratio (IHF): 110 dB
    Gain:0 dB (flat position)
    Power consumption: 10 W
    Weight: Black version 4,6 kg

    10-band left / right independent variable slide volume. Equalization: same setting as an ISO standard professional machine. With a spectrum analyzer that displays the level of left / right signal alone or as a mix of left / right signals. Special feature: peak hold function, lasting for 3-4 seconds. Two tape inputs, monitor and dubbing can be chosen independently. Defeat position switch. When depressed, signal passes without any influence by the equalizer-circuit.

  • Net weight (2.2 lb = 1 kg)
  • 4.4 kg / 9 lb 11.1 oz (9.692 lb)
  • Mentioned in
  • - - Manufacturers Literature (Bedienungsanleitung Sansui SE-8)
  • Literature/Schematics (1)
  • Sansui Katalog 1980
  • Author
  • Model page created by Peter Liska. See "Data change" for further contributors.
