• Country
• Japan

• Manufacturer / Brand
• Sansui Electric Co., Ltd.; Tokyo

• Year
• 1970/1971 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 80605

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 46

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 100; 110; 117; 127; 220; 230; 240; 250 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 56 W (70 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo Tuner Amplifier 1000X - Sansui Electric Co., Ltd.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 416 x 145 x 300 mm / 16.4 x 5.7 x 11.8 inch

• Notes

• A hi-fi receiver housed in a walnut case with an AM/FM multiplex stereo tuner with an analogue dial and an amplifier with continuous output power of 2 x 28 watts into 8 ohms or 2 x 35 watts into 4 ohms. The preamplifier and power amplifier sections can be separated. With 100 watts IHF music power, 2-microvolt IHF sensitivity, FET front end, blackout dial, automatic stereo/mono switching, tuning meter, FM muting, two tape monitors, two-system speaker selector, dual-impedance antenna inputs, Headphone jack, Scratch filter and Loudness switch.

  Zwei direkte Hinterbandkontrollen, getrennt für jeden Kanal regelbare Bässe und Höhen, getrennt verwendbare Vor und Endstufe.

  Semiconductors: 45 Transistors, 1 FET, 22 Diodes
  Power requirements: 100,110,117,127,220,230,240,250V AC 50/60Hz internally switchable
  Power consumption: 60 watts

• Net weight (2.2 lb = 1 kg)
• 10.3 kg / 22 lb 11 oz (22.687 lb)

• Price in first year of sale
• 1,285.00 DM

• Source of data
• -- Original-techn. papers.

• Mentioned in
• -- Original prospect or advert (1971 Sansui Stereo Components catalogue)

• Literature/Schematics (1)
• - - Manufacturers Literature (Service manual Sansui 1000X and Service Bulletin dated July 1970)

• Literature/Schematics (2)
• - - Manufacturers Literature (Operating Instructions Sansui 1000X)

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
