Stereophonic Amplifier AU-111

• Country
• Japan

• Manufacturer / Brand
• Sansui Electric Co., Ltd.; Tokyo

• Year
• 1965–1969

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 115211

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• 12AX7 12AX7 12AX7 12AX7 12AX7 12BH7A 12BH7A 6AQ8 6L6GC 6L6GC 6L6GC 6L6GC

• Number of Transistors
• 2

• Semiconductors
• 2SC402 2SC402

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 100; 117; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 80 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereophonic Amplifier AU-111 - Sansui Electric Co., Ltd.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 459 x 170 x 345 mm / 18.1 x 6.7 x 13.6 inch

• Notes

• A hi-fi stereo integrated amplifier housed in a metal case with power output of 2 x 40 watts RMS both channels driven into 8 ohms, THD 0.8%.

• Net weight (2.2 lb = 1 kg)
• 24.5 kg / 53 lb 15.4 oz (53.965 lb)

• Source of data
• -- Collector info (Sammler)

• Mentioned in
• -- Original prospect or advert (1969 Sansui Stereo catalogue)

• Literature/Schematics (1)
• - - Manufacturers Literature (Operation Instructions and Service manual Sansui AU-111)

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
