• Country
• Japan

• Manufacturer / Brand
• Sanwa

• Year
• 1980 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 82969

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 310HEB4

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch

• Power out
• 1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 3004 - Sanwa

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 393 x 283 x 295 mm / 15.5 x 11.1 x 11.6 inch

• Notes

• S/W-Fernseher, Bildrohr Bildschirmdiagonale 290 mm. Teleskopantenne + Anschluß für ext. Antenne.

  Gleiches Modell jedoch Batterie / Netzbetrieb siehe Sanwa 3005

• Net weight (2.2 lb = 1 kg)
• 11 kg / 24 lb 3.7 oz (24.229 lb)

• Author
• Model page created by Arndt Markus Hettche. See "Data change" for further contributors.

• Other Models

• Here you find 49 models, 41 with images and 6 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Sanwa
