4 Band Radio Stereo Cassette Recorder 7059

Sanwa

Data
Forum
Pictures
Collections

  • Manufacturer / Brand
  • Sanwa
  • Year
  • 1982 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 199453

 Technical Specifications

  • Number of Transistors
  • 26
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 220 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 4 Band Radio Stereo Cassette Recorder 7059 - Sanwa
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 406 x 257 x 118 mm / 16 x 10.1 x 4.6 inch
  • Notes
    • Stereo Radiorecorder
    • 4 Bänder (LMKU)
    • UKW bis 108 Mhz
    • LED-Stereo-Anzeige
    • Feldstärke-Anzeige
    • AFC
    • getrennte Höhen- und Bassregelung
    • Balance-Regler
    • 2 eingebaute Mikrofone (linker und rechter Kanal)
    • Kassettenlaufwerk mit Vor- und Rückspul- und Aufnahmefunktion
    • Anschluss für
      • Line In/Out
      • externe Mikrofone
      • externe Lautsprecher
      • Phono/Tape
      • Kopfhörer
      • externe Antennen
  • Author
  • Model page created by Philip Obetsanov. See "Data change" for further contributors.
  • Other Models

  • Here you find 49 models, 41 with images and 6 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
