• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 208662

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 100; 120; 200; 240; 8 x 1,5; 12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 3 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 4 Band Radio Cassette Recorder M9980K - Sanyo Electric Co. Ltd.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 418 x 262 x 110 mm / 16.5 x 10.3 x 4.3 inch

• Notes
• 4 Band Radio Cassette Recorder (50 - 12000Hz Chrome).
  Frequency Range: MW 530-1605kHz, SW1 2,3-7,0MHz, SW2 7,0-22MHz, FM 87,5-108MHz.
  Power Source: DC: 12 volts with 8 "D" size cells or 12V Car battery adaptor.

• Net weight (2.2 lb = 1 kg)
• 4.8 kg / 10 lb 9.2 oz (10.573 lb)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
