4Band Stereo Cassette Recorder M9709L

Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Data
Forum
Pictures
Collections

  • Year
  • 1992 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 286797

 Technical Specifications

  • Number of Transistors
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 120; 220 / R20: 6 x 1,5 Volt
  • Loudspeaker
  • 4 Loudspeakers / Ø 11 cm = 4.3 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 4Band Stereo Cassette Recorder M9709L - Sanyo Electric Co. Ltd.;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 470 x 195 x 97 mm / 18.5 x 7.7 x 3.8 inch
  • Notes

  • Stereo-Kassetten-Radiorecorder mit eingebautem Mikrofon; FM-Empfang über 70 cm Teleskopantenne, AM-Empfang über interne Ferritantenne; Feinabstimmung für Kurzwelle; Aufnahmemöglichkeit über DIN-Anschluss; Kopfhöreranschluss: 3,5 mm Klinkenbuchse.

  • Net weight (2.2 lb = 1 kg)
  • 2.536 kg / 5 lb 9.4 oz (5.586 lb)
  • Author
  • Model page created by Michael Mischke. See "Data change" for further contributors.
