• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1973 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 207669

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• 2SB303 2SB185 2SB186 2SB187 2SB405 2SB405

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 120-240/4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Power out
• 1.5 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Cassette Tape Recorder MR-410 - Sanyo Electric Co. Ltd.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 10 x 6.25 x 2.75 inch / 254 x 159 x 70 mm

• Notes
• Note: This model also accepts 1x Sanyo Cadnica rechargeable battery.

• Net weight (2.2 lb = 1 kg)
• 4.8 lb (4 lb 12.8 oz) / 2.179 kg

• Source of data
• - - Data from my own collection

• Author
• Model page created by Anthony Alston. See "Data change" for further contributors.
