FM/MW/LW Stereo Receiver JCX 2100LZ

Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Data
Forum
Pictures
Collections

  • Year
  • 1978 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 343039

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz, 115; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 30 W (40 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: FM/MW/LW Stereo Receiver JCX 2100LZ - Sanyo Electric Co. Ltd.;
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 420 x 140 x 300 mm / 16.5 x 5.5 x 11.8 inch
  • Notes

  • FM/MW/LW Stereo Receiver

    • Power Output: 15 watts per channel into 8 Ω
    • Frequency response: 20 Hz to 30 kHz
    • Total harmonic distortion: 0.5%
    • Input sensitivity: 2.5 mV (MM), 150 mV (line)
    • Signal-to-noise ratio: 70 dB (MM), 90 dB (line)
    • Output: 150 mV (line)
    • Built-in ferrite rod antenna for LW and MW.
  • Net weight (2.2 lb = 1 kg)
  • 7.5 kg / 16 lb 8.3 oz (16.52 lb)
  • Author
  • Model page created by Francisco Martins. See "Data change" for further contributors.
