• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1981 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 342091

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors
• NJM4558 LP2902 LP2902 LP2902 LP2902 2SC1317

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Graphic Equalizer FT-E30 - Sanyo Electric Co. Ltd.;

• Shape
• Chassis only or for «building in»

• Notes

• Sanyo 7-Band Graphic Equalizer FT-E30 for usage in car hifi systems.

  3 Si-diodes.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
