• Country
• Spain

• Manufacturer / Brand
• Sanyo España, Sonitrón, Eurotrón, Ainsa; Huesca (HU) y Tudela (NA)

• Year
• 1974/1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 199810

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors
• BF194 BF194 BF194 BF196 BF197 BF197 BC148 BC147 BC148 BC147 AC188 AC188 AC188 BA182 BA182 AA119 AA119 AA119 AA119 AA119 AA119 AA119 AA119 F12 F12

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 127; 220 / 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch

• Power out
• 2 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: M-2455LZS - Sanyo España, Sonitrón, Eurotr

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 365 x 227 x 95 mm / 14.4 x 8.9 x 3.7 inch

• Notes
• Radio transistor con grabación y reproduccion de cassette. Lleva 12 diodos y 1 FET. 4 bandas, sintonia fina, vumetro con doble función que indica tanto el volumen como el estado de las pilas, microfono interno, función SLEEP, entrada auxiliar, interruptor monitor-altavoz.

• Net weight (2.2 lb = 1 kg)
• 3.1 kg / 6 lb 13.3 oz (6.828 lb)

• Mentioned in
• Esquemario de Magnetófonos y cassettes III 1976

• Author
• Model page created by Juan Bautista Ruiz Pérez. See "Data change" for further contributors.
