Micro S 6C-64 (Japan 704)
Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
- Country
- Japan
- Manufacturer / Brand
- Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
- Year
- 1968 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 281101
- Number of Transistors
- 6
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 6LR61: 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
- Power out
- 0.2 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Micro S 6C-64 - Sanyo Electric Co. Ltd.;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 92 x 60 x 28 mm / 3.6 x 2.4 x 1.1 inch
- Notes
-
MW Taschenempfänger in Kunstlederetui mit 3,5mm Ohrhöreranschluss.
Empfangsbereich: MW: 510 - 1620 kHz.
Made in Japan 704
- Net weight (2.2 lb = 1 kg)
- 0.141 kg / 0 lb 5 oz (0.311 lb)
- Author
- Model page created by Holger Struthoff. See "Data change" for further contributors.
