IC Mini Cassette Tape Recorder M-508P

Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Data
Forum
Pictures
Collections

  • Year
  • 1973 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 312487

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Batteries / addl. power jack / AA: 3 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 0.3 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: IC Mini Cassette Tape Recorder M-508P - Sanyo Electric Co. Ltd.;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 89 x 140 x 36 mm / 3.5 x 5.5 x 1.4 inch
  • Notes

  • 2 IC's.

  • Net weight (2.2 lb = 1 kg)
  • 0.628 kg / 1 lb 6.1 oz (1.383 lb)
  • Mentioned in
  • -- Collector info (Sammler)
