- Country
- Japan
- Manufacturer / Brand
- Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
- Year
- 1967–1971
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 150388
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Line / Batteries (any type) / 115; 230 / D: 6 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1.2 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: MR-115 - Sanyo Electric Co. Ltd.;
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 295 x 98 x 270 mm / 11.6 x 3.9 x 10.6 inch
- Notes
-
Sanyo MR115 Tape Recorder
AC-battery operated, two-speed tape recorder. Seven transistors and one diode. Speaker, 6¼" x 3⅛" (8 Ω); output 1.2 W.
Features: tape speeds, 1⅞ and 3¾ ips (4.8 / 9.5 cm/sec); frequency response, 15 - 6000 Hz at 3¾ ips.
Operates from six Type D cells or 230 V AC. Remote stop-start switch on microphone; 5" reels; 3-digit tape counter. Supplied with microphone, one 5", AC cord, etc. (MINGAY'S PRICE SERVICE)
- Net weight (2.2 lb = 1 kg)
- 4.3 kg / 9 lb 7.5 oz (9.471 lb)
- Price in first year of sale
- 3,890.00 HUF
- Mentioned in
- Mingay's Price Service (Feb 1968 to Feb 1971.)
- Literature/Schematics (1)
- -- Original-techn. papers. (Sanyo Service Manual)
