• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1971/1972

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 104150

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 20; 200; 240 / C: 4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch

• Power out
• 1.5 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: MR-4141 - Sanyo Electric Co. Ltd.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 280 x 150 x 60 mm / 11 x 5.9 x 2.4 inch

• Notes
• Custodia supplementare in gomma, antenna stilo telescopica da 70 cm. Alimentazione a batterie con 4 1/2 torcia, cavo rete asportabile con spina doppia ITA/USA.

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• Price in first year of sale
• 190.00 AUS $

• Mentioned in
• Mingay's Price Service (Aug 1971 & Feb 1972.)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Andrea Furlanis. See "Data change" for further contributors.
