• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1985 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 215991

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 120; 200; 240 / 5 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Radio Cassette Recorder M 2560N - Sanyo Electric Co. Ltd.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 325 x 210 x 80 mm / 12.8 x 8.3 x 3.1 inch

• Notes
• OM: 530-1600 kHz.
  OC: 3.2-12.0 MHz.
  FM: 88-108 MHz.
  Tomadas; AC Input, Mic, Ear. Cassette Auto Stop.
  Variable Monitor System. Antena Telescopica.

• Mentioned in
• Le grand livre de la TSF (Nº fiche=19687)

• Author
• Model page created by João-Afonso Santos. See "Data change" for further contributors.
