Solid State Stereo Ampli-Tuner DC-710K

Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Data
Forum
Pictures
Collections

  • Year
  • 1970 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 352579

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 22
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz; 3 AF stage(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 50/60 Hz, 120; 230 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 32 W (45 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Solid State Stereo Ampli-Tuner DC-710K - Sanyo Electric Co. Ltd.;
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 450 x 670 x 345 mm / 17.7 x 26.4 x 13.6 inch
  • Notes

  • Sanyo Model DC720K

    2-channel console with 2-band radio tuner.

    Features: AM/FM tuner; 40 watts P.M.P.; 8" woofer, 4" squawker and 2-⅜" tweeter; sealed type front speaker enclosure; 2-speed Sanyo auto return tone arm with cartridge MGT-V and diamond stylus ST-14D; 11" platter; slide bass, treble, balance and volume controls, with separate volume control for mic. mixing. Headphone jack.

    Speaker unit dimensions: 450 x 670 x 345 mm. Weight 11 kg each.

  • Net weight (2.2 lb = 1 kg)
  • 18.5 kg / 40 lb 12 oz (40.749 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
