Stereo Amplifier DCA1400
Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
- Country
- Japan
- Manufacturer / Brand
- Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
- Year
- 1980 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 332441
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 24
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 120, 200, 220, 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 20 W (28 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Amplifier DCA1400 - Sanyo Electric Co. Ltd.;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 11 x 10 x 4 inch / 279 x 254 x 102 mm
- Notes
-
DCA1400 Solid State Stereo Amplifier
Specifications:
Power output: 20 watts per channel into 8 Ω (stereo)
Frequency response: 15 Hz to 70 kHz
Total harmonic distortion: 0.8%
Input sensitivity: 2.5 mV (MM), 100 mV (line)
Speaker load impedance: 4 Ω to 16 Ω
Semiconductors: 24 x transistors, 22 x diodes
- Net weight (2.2 lb = 1 kg)
- 10 lb 0 oz (10 lb) / 4.540 kg
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (2)
- -- Original-techn. papers.
- Author
- Model page created by Jesús Casado Arriazu. See "Data change" for further contributors.
