Stereo Amplifier DCA-200 /MV /SEV /UK
Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
- Country
- Japan
- Manufacturer / Brand
- Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
- Year
- 1975 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 352653
Picture from manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 27
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 50/60 Hz, 120; 200; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 26 W (40 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Amplifier DCA-200 /MV /SEV /UK - Sanyo Electric Co. Ltd.;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 405 x 185 x 365 mm / 15.9 x 7.3 x 14.4 inch
- Notes
-
Sanyo Model DCA-200
Input: Sensitiviy/impedance
- Phono: 2.5 mV/50 kΩ
- Tuner: 150 mV/50 kΩ
- Aux: 150 mV/50 kΩ
- Tape, 1, 2: 150 mV/50 kΩ
- Mic: 150 mV/50 kΩ
Mains for MV version. SEV 120/220 (50Hz), UK 240 (50 Hz)
Each semiconductor type listed once
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
