Stereo Cassette Tape Recorder M9970K

Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Data
Forum
Pictures
Collections

  • Year
  • 1978 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 341615

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 15
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 5 AM circuit(s)     8 FM circuit(s)
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line plus power jack, mostly with battery or storage battery / 50-60 Hz, 100-120; 200; 240 / DC 9 / D: 6 x 1.5 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 6 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Stereo Cassette Tape Recorder M9970K - Sanyo Electric Co. Ltd.;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 410 x 250 x 122 mm / 16.1 x 9.8 x 4.8 inch
  • Notes

  • Sanyo portable stereo radio cassette recorder Model M9970K

    Wave bands:

    • FM = 88 - 108 MHz
    • MW = 525 - 1605 kHz
    • SW1 = 2.2- 7.1 MHz
    • SW2 = 7 - 22.1 MHz

    Dual 2-way co-axial speakers
    Illuminated sound level indicator

    Frontloading cassette Player/Recorder, Full Auto Stop, Tape selector
    Cue review and mechanical pause functions

    Carrying handle
    Telescopic antenna

    Solid state devices: listed once per type, but not all.
    Weight including batteries.

    Made in Malaysia

    See also

    • Sanyo M9970 with AM/FM bands for the US market.
    • Sanyo (Spain) M9970L
  • Net weight (2.2 lb = 1 kg)
  • 4.7 kg / 10 lb 5.6 oz (10.352 lb)
  • Mentioned in
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
