- Country
- Italy
- Manufacturer / Brand
- SARCA (S.A.R.C.A., SARKA); Milano
- Year
- 1975 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 181451
- Number of Transistors
- 9
- Semiconductors
- BF234 BF234 BF235 BF235 BC205 BC208 unknown_tr unknown_tr unknown_tr
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 220 / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: S-327 - SARCA S.A.R.C.A., SARKA;
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 275 x 170 x 80 mm / 10.8 x 6.7 x 3.1 inch
- Notes
-
On the top four buttons: on/off, battery/main, AFC, FM/MW. Non-detachable power cord. No jacks.
Superiormente 4 tasti: accensione, pile/rete, AFC , FM/OM. Cavo per alimentazione elettrica non staccabile. Nessuna presa. Diverse varianti di colore (verde, rosso, ecc.)
- Net weight (2.2 lb = 1 kg)
- 1.7 kg / 3 lb 11.9 oz (3.744 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Felice Nicolini. See "Data change" for further contributors.
- Other Models
-
Here you find 42 models, 40 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from SARCA (S.A.R.C.A., SARKA); Milano
