• Country
• Italy

• Manufacturer / Brand
• Savigliano, Officine di, SA; Savigliano (CN)

• Year
• 1937–1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 233379

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 6A8G 6B8G 6F6G 5Y3G

• Main principle
• Superheterodyne (common); Reflex

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 97 - Savigliano, Officine di, SA;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 240 x 190 x 180 mm / 9.4 x 7.5 x 7.1 inch

• Price in first year of sale
• 790.00 ITL

• Literature/Schematics (1)
• Il Radio Libro, (Ravalico) 6a edizione 1942

• Author
• Model page created by Leonardo Mureddu. See "Data change" for further contributors.
